BHMTPMPA Series Bis (Hexamethylene Triamine Penta (Methylene Phosphonic Acid))
RAW MATERIAL
BHMTPMPA

BHMTPMPA Series Bis (Hexamethylene Triamine Penta (Methylene Phosphonic Acid))

BHMTPMPA Series Bis (Hexamethylene Triamine Penta (Methylene Phosphonic Acid)) is a dark amber, water-soluble phosphonate raw material used for chelation, scale control, and corrosion-control applications in industrial water treatment.

Chemical Name
Bis (Hexamethylene Triamine Penta (Methylene Phosphonic Acid))
Molecular Weight
685
Molecular Formula
C17H44O15N3P5
EINECS
252-156-6
PRODUCT OVERVIEW

Product Description

BHMTPMPA Series Bis (Hexamethylene Triamine Penta (Methylene Phosphonic Acid)) is a phosphonate-based industrial raw material supplied as a dark amber liquid. It is characterized by good water solubility and is primarily used in professionally managed water-treatment and process-water systems. The material provides effective chelating and scale-control properties, particularly against carbonate and sulfate deposits. It also demonstrates good thermal stability across a broad pH range and retains functional stability under elevated-temperature conditions. BHMTPMPA is valued for its calcium-ion tolerance and is used in specialized industrial formulations where mineral-scale control and corrosion-management performance are required. Typical application sectors include oilfield water treatment, industrial circulating cooling-water systems, boiler-water treatment, and related process-water applications. The referenced specification controls active content, phosphorous acid, chloride, iron, pH, density, and physical appearance. Final product selection and use should follow the relevant technical specification, Safety Data Sheet, regulatory requirements, and professional chemical-handling procedures.
PRODUCT PARAMETERS

General Parameters

Physical Form
Liquid
Appearance
Dark amber liquid
Water Solubility
Excellent
Chemical Character
Acidic
Thermal Stability
Stable under elevated-temperature conditions up to approximately 120°C
KEY PROPERTIES

Product Characteristics

Provides effective chelating performance for industrial water-treatment formulations.
Helps control carbonate and sulfate scale formation in professionally managed water systems.
Offers excellent water solubility for incorporation into aqueous industrial formulations.
Maintains good thermal stability across a relatively broad pH range and under elevated-temperature conditions.
Demonstrates good tolerance to calcium ions, supporting performance in mineral-rich water-treatment environments.
Combines scale-control and corrosion-management functionality for selected industrial process-water applications.
TECHNICAL SPECIFICATIONS

Specification Data

Specification Standard
Appearance Dark amber liquid
Content by wt % 45.0 - 50.0
Phosphorous acid by wt % 3.5 max
Chloride (Cl-) by wt % 6.0 max
Fe by mg/L 35.0 max
pH value (1% water solution) 2.0
Density (20°C) by g/cm3 1.2 min
APPLICATIONS

Typical Uses

Used as an industrial chelating and scale-control ingredient for systems where carbonate and sulfate deposits must be managed.
Applied in professional water-treatment formulations requiring good water solubility and thermal stability across a broad operating pH range.
Used in oilfield water-treatment applications as a functional ingredient for scale and corrosion-management formulations.
Suitable for industrial circulating cooling-water treatment systems requiring controlled scale-inhibition performance.
Applied in professionally managed boiler-water treatment systems where phosphonate-based scale-control functionality is required.
Used in selected industrial process-water formulations that require calcium tolerance and mineral-deposit control.
STORAGE & HANDLING

Handling Guidance

Store in securely closed and appropriately labeled containers in a cool, dry, and well-ventilated area. Protect the material from direct sunlight, excessive heat, moisture, and incompatible substances. The material is acidic and should be handled only under appropriate industrial chemical-safety procedures. Avoid direct contact with the skin and eyes, and follow the applicable Safety Data Sheet, workplace protective-equipment requirements, and local chemical-safety regulations. Keep containers closed when not in use and follow approved procedures for storage, transport, spill response, and disposal. Product compatibility and handling requirements should be confirmed from the supplier-specific Safety Data Sheet before professional use.
